Specification
| Eyepiece | Wide field WF10X (Φ22mm) |
| Division eyepiece 10X (Φ22mm) 0.10mm/div | |
| Infinity Plan Objective, Strain-free | PL4x/0.10, WD=19.8mm |
| PL 20x/0.40 , WD= 8.8mm | |
| PL40x/0.65, WD=0.66mm | |
| PL60x/0.8, WD=0.45mm | |
| Head | Trinocular, Inclination 30°, send 100% of the image light to top photography port |
| Intermediate | Built-in bertrand lens |
| Transmitted Illumination | Polarizer 360 Degree rotatable, have 0,90,180,270 four scale |
| Collector For halogen lamp illumination | |
| Illumination 6V 30w, halogen lamp, adjustable brightness | |
| Abbe condenser rack & pinion adjustable | |
| Compensator | λ compensator |
| λ/4 compensator | |
| Quarts wedge compensator | |
| Focus System | Coaxial coarse/fine focus, with tension adjustable and up stop minimum division of fine focusing: 0.002mm |
| Nosepiece | Quadruple(Backward ball bearing inner locating, center adjustable) |
| Stage | Rotatable stage, Diameter Φ150mm, 360°graduated (in 1° increments), minimum retardation resolution 6′ center adjustable and with tightener |
Optional accessories
| Eyepiece | Wide field eyepiece WF16X(Φ11mm) |
| Infinity Plan Objective, Strain-free | PL 10X/0.25 (Work distance)：5.0mm |
| PL 60X/0.80 (Work distance)：0.46mm | |
| PL 100/1.25 (Work distance)：0.33mm | |
| Nosepiece | Quintuple(Backward ball bearing inner locating, center adjustable) |
| Slide Moving Holder | Moving range: 30mmX25mm |
| CCD Adapter | 0.4X, 1.0X |
| 0.5X with dividing 0.1mm/Div | |
| Digital Adapter | Canon EOS Digital adapter |
