Specification
| Type of sensor | Color CMOS Image Sensor |
| Sensor size | 1/2.8 Inch |
| Pixel size | 2.9 µm (H) × 2.9 µm (V) |
| Resolution ratio | 1920 X 1080 |
| Exposure control | Auto / Manual |
| Power Frequency | DC / 50Hz / 60Hz |
| White balance control | Auto WB / Once WB / Manual |
| Cross-line | 4 Sets |
| Calibration and measurement | Support Calibrating and line measuring |
| Snap | Button snap / timed snap |
| Video recording | Supported |
| Frame rate | 30FPS@1920*1080 |
| Image adjusting Parameters | Saturation/ Hue / Brightness / Contrast / Monochrome / Flip vertical / Flip horizontal / FOV |
| FOV | 20%-100% |
| Storage for snap and record | TF card |
| Language | English / Chinese |
| Firmware Software Update | Supported |
| Overall dimensions | 182mm*125mm*85mm |
