Specification
| Eyepiece | Wide field WF10X(Φ18mm) |
| Objective | Plan achromatic objectives with long working distance (no cover glass) PLL10X/0.25 |
| Plan achromatic objectives with long working distance (no cover glass) PLL20X/0.40 | |
| Plan achromatic objectives with long working distance (no cover glass) PLL40X/0.60 | |
| Plan achromatic objectives with long working distance (no cover glass) PLL100X/1.25(Spring, oil) | |
| Eyepieces tube | Trinocular, 30˚ inclined |
| Filter | Frosted filter, blue filter, Green filter, yellow filter |
| Focus system | Coaxial coarse/fine focus system, with tensional adjustable and up stop, minimum division of fine focusing: 2μm. |
| Nosepiece | Quadruple (Ball bearing inner locating) |
| Stage | Double layer mechanical (Size:180mmX150mm, moving range:15mmX15mm) |
| Illumination unit | 6V 20W halogen lamp, brightness control. |
Optional Accessory
| Eyepiece | Wide field WF16X(Φ11mm) |
| Dividing 10X(Φ18mm) 0.1mm/Div | |
| Objective | Plan achromatic objectives with long working distance (no cover glass) PLL 60X/0.75(Spring) |
| Plan achromatic objectives with long working distance (no cover glass) PLL 100X/0.85 (Spring) | |
| Achromatic objectives (no cover glass) 60X/0.85 | |
| Nosepiece | Quintuple (Ball bearing inner locating) |
| CCD adapter | 0.4X |
| 0.5X | |
| 1X | |
| 0.5X with dividing 0.1mm/Div | |
| Photo unit | 2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
| Digital camera adapter | CANON (A610, A620, A630, A640) |
