Specification
| Head | Seidentopf trinocular head, inclined 45°, interpupillary distance: 48-76mm, with Light distribution Knob for two types splitting ratio: 100: 0（100% for eyepiece） 80:20 (80% for trinocular head, and 20% for eyepiece) |
| Eyepiece | WF10X/22mm（23mm is optional） |
| Objectives | LWD infinity plan objective 4X/0.11, W.D.=12.1mm |
| LWD infinity plan objective 20X/0.40, W.D.=7.2mm | |
| LWD infinity plan objective 40X/0.60, W.D.=3.4mm | |
| LWD infinity plan phase contrast objective 10X/0.25, W.D.=8.3mm | |
| Nosepiece | Quintuple |
| Annular Spot | 10X |
| Mechanical Stage | Stage size: XXY: 210X241mm, Round slide size: Φ118mm, attached mechanical stage (available for 96 holes plate, moving range XXY: 128X80mm.) |
| Condenser | Long working distance, quickly detachable, N.A.0.3, Working distance: 72-365mm (with condenser), 480mm (without condenser). |
| Illumination | 10W LED |
Optional accessories
| LWD Infinity Plan Objectives | LPLAN 10X/0.25 W.D.=8.3mm |
| Annular Spot | 10X |
| Culture Dish Holder | 65mm |
| 35mm | |
| Filter | Amber |
| Grey | |
| C-mount | 1X C-Mount (better for digital photograph) |
| 0.5X C-Mount (focus adjustable, better for digital camera) | |
| Adaptor for Digital SLR Camera | Use for CANON/NIKON/OLYMPUS etc. |
| Epi Fluorescence Illumination | Epi fluorescence unit, field diaphragm, center adjustable. |
| 100W mercury lamp (OSRAM) | |
| B, G, V, UV fluorescence filters can be chosen. | |
| Digital mercury lamp power box (input voltage:100V～240V) |
