Specification
| Item | Specification | 300V | 300H |
| LWD Infinity Plan Objectives | L Plan FL 4X／0.11 W.D.=12.1mm | s | s |
| L Plan FL10X／0.25 W.D.=10.3mm | o | o | |
| L Plan FL20X／0.45 W.D.=5.8mm | o | o | |
| L Plan FL 40X／0.65 W.D.=5.1mm | o | o | |
| LWD Infinity Plan Phase Contrast Objectives | L Plan FL PHP 10X/0.25W.D.=10.3mm | s | s |
| L Plan FL PHP 20X/0.45 W.D.=5.8mm | s | s | |
| L Plan FL PHP 40X/0.65 W.D.=5.1mm | s | s | |
| Annular Spot | 10X | s | s |
| 20X/ 40X（for both 20X and 40X） | s | s | |
| Nosepiece | Quadruple | s | s |
| Stage | Mechanical Stage, Stage size: 180 mmX155mm, Moving range:75X40mm | s | s |
| Scale: 0.1mm, Round slide dia.：110mm | |||
| Mixed stage, Stage size: 180 mmX203mm | o | o | |
| Glass Holder(outside dia 110mm, inside dia 30mm)） | s | s | |
| Drop-shaped Metal Holder(outside dia 110mm, inside dia25mm） | o | o | |
| Condenser | Long working distance, N.A.0.32, Working distance 48mm | s | s |
| Coaxial Coarse and Fine Focusing unit | Coarse stroke: 10mm, | s | s |
| Fine stroke per rotation: 0.2mm, fine division 2 μm. | |||
| Illumination | 5W LED, input voltage：100V～240V | s | s |
| Filter | Green(21mm) | s | s |
| Blue /Yellow /Grey (21mm) | o | o | |
| C-mount | 0.65X(built-in) | s | s |
| Image System | 11.6” Tablet Screen(Windows system) | s | – |
| Built-in DV630 630mp USB3.0 digital camera | s | – | |
| 11.6” HDMI Screen | s | ||
| HDMI4Kdigital camera (with U-disk interface) | s | ||
| Note: s: Standard accessories; o: Optional accessories | |||
