Key Features
- Long working distance enable users to handle large specimen
- 5X and 10X widefield stereo magnification powers
- Adjustable gooseneck LED light offering flexible illumination
Specification
| Name of Parts | Specification | DUP09D2LP | DUP09D2P |
| Head | The Left Ocular-tube with diopter adjustment 5DP, the Interpupillary Distance: 55-75mm | ● | ● |
| Eyepiece | WF5X and WF10X | ● | ● |
| Objective | 1X | ● | ● |
| Working Distance | 230mm | ● | ● |
| Light Source | Incandescent Lamp 12V/10W 6V/6W | – | ● |
| High Brightness LED Point Light 3W | ● | – |
Technical Data
| Objective | EYEPIECES | Working Distance | |||||||
| 5X | 10X | 15X | 20X | ||||||
| Mag. | Field of View | Mag. | Field of View | Mag. | Field of View | Mag. | Field of View | ||
| 0.5X | 2.5X | 40.0mm | 5X | 40.0mm | 7.5X | 30.0mm | 10X | 20.0mm | 250mm |
| 1X | 5X | 20.0mm | 10X | 20.0mm | 15X | 15mm | 20X | 10.0mm | 230mm |
Optical Accessories
| Eyepiece | WF15X |
| WF20X | |
| Objective | 0.5X |
