Features
- Adopting Infinity Achromatic Optical System
- Four Wide-field magnification settings: 40X, 100X, 200X, 400X, 1000X
- High cost performance with high quality accessories
Specification
| Head | Infinity binocular, inclined 30°, rotatable 60°, interpupillary distance 50-75mm | |
| Eyepiece | WF10X/20mm | |
| Infinity Plan Objectives | 4X /0.10 | WD=100MM |
| 10X /0.25 | WD=4.19MM | |
| 20X /0.40 | WD=2.41MM | |
| 40X (S) /0.66(S) | WD=0.45MM | |
| 100X /1.25(Oil) (S) | WD=0.12MM | |
| Nosepiece | Quintuple | |
| Focusing | Coaxial coarse and fine focusing knob | |
| Stage | Double layer mechanical, size 190x140mm, moving range 78x55mm | |
| Condenser | Abbe N.A.1.25 with aperture iris diaphragm | |
| Filter | Blue | |
| Light source | 6V 20W halogen lamp with brightness control | |
| Packing info | 1pc/carton, Carton size 54x29x39cm, Gross weight 12 Kgs | |
Optional Accessories
| Items | Specification |
| Eyepiece | WF 16X-13 mm |
| WF 10X-20 mm ( 0.1mm) | |
| Infinity Plan Objectives | 2.5X /0.07 |
| 60X /0.80（S） | |
| Nosepiece | Quadruple Nosepiece |
| Condenser | Swing out condenser N.A.0.9/0.13 |
| Koehler Illumination | 6V/30W Halogen Lamp |
| 3W-LED Illumination | |
| Polarizing Set | Analyzer+ Polarizer |
| Phase Contrast Unit | Quintuple hole turret 10X /20X /40X /100X phase contrast objective |
| Independent slot 10X /20X /40X /100X phase contrast objective | |
| Dark Field Condenser | Dark Field Condenser N.A1.25 (Oil) |
| Dark Field Condenser N.A.0.9 (Dry) | |
| C-mount | 1X |
| 0.57X (Focus adjustable) | |
| Fluorescence Attachment | Epi Fluorescence unit ( six-hole disc, U/V/B/G) |
| Epi Fluorescence unit (three-hole slide, B/G) | |
| Filter | Green |
| Amber |
