Key Features
- Adopting infinity optical system
- Phase contrast optics offering high contrast observation
- Super large working stage and multiple culture dish holder choices
Specification
| Optical system | Infinity optical system |
| Head | Trinocular head, inclination at 45°，can be shot in 100% light flux，interpupillary distance: 48 ~75mm |
| Eyepiece | WF10X(Φ22mm) (Dia.30mm for Eyepiece Tube), Parfocal distance: 10mm |
| Centering telescope | |
| Objective | Infinity plan achromatic objective 10x, 20x, 40x |
| Infinity Phase-contrast objective PH10X | |
| Nosepiece | Quadruple |
| Focus System | Coaxial coarse/fine focus, with tension adjustable and up stop, minimum division of fine focusing is 2μm. |
| Stage | Mechanical stage, moving range 112x77mm, detachable mechanical stage |
| Culture dish holder | Adjustable Petri Dish Holder. Internal slot dimensions: 82mm×56mm, 77mm×33mm, 77mm×26mm. Suitable for Petri dishes with diameters of 35mm, 50mm, 60mm and 68mm. |
| Phase contrast set | Flashboard phase contrast condenser, center of phase contract ring adjustable |
| Illumination | 9W LED, brightness adjustable |
| Filter | Blue, frosted |
