Specification
| Magnification | 3.8x~230x | |
| Head | Binocular Head, 30° inclined, interpupillary distance 48~75mm, Diopter +/-5 adjustable | |
| With VIDEO port and PHOTO port | ||
| Eyepiece | WF10x/22mm, High Eyepoint | |
| WF20x/12mm, High Eyepoint | ||
| Objective | 5 Step Zoom Plan Objective 0.8x, 1.25x, 2x, 3.2x, 4.8x | |
| Auxiliary Lens 0.4x, 2.0x | ||
| Working Distance | 101mm | |
| View Field | Diameter 2.3~62mm | |
| Magnification Correcting | Magnification Correction System, with Correcting Lens | |
| Separation Line Adjusting | Separation Line Adjust System in Back, with Special Designed Adjustment Driver | |
| Working Stage | Square Manual Working Stage 90*90mm, Moving Range 54*54*54mm | |
| Round Tiltable Working Stage Dia. 90mm, 0-45° Inclined, 360° Rotatable | ||
| Joint Left/Right Moving Range 54mm, Joint Up/Down Range 60mm | ||
| Bullet Holder | Bullet Holder Set for all kinds of Bullet, Cartridge and other Objects | |
| Light Source | 12v 50w fan cooling strong halogen light, brightness adjustable (pair) | |
| 5w led cold light, high brightness, brightness adjustable (pair) | ||
| Coaxial Light Lens for observing in deep hole, or smooth object surface (Pair) | ||
| Polarizing Light Lens, for eliminating flare lights and dazzling lights (Pair) | ||
| Filters: red, green, uv | ||
| Adapter | Built-in 0.5x CCD Adapter | |
| Front View Photo Adapter for SLR Digital Camera | ||
| Easy to view and take photos | ||
| Power | 80~240v wide range voltage | |
| Dimension | Instrument Size 37*30*63cm | |
| Packing case | Aluminum Case Packing. Convenient for carrying and storing | |
| Optional accessories | ||
| Light source | 150w cold light source, with optical fiber & light collector | |
| 7″ pad digital camera | 7-inch lcd pad digital camera, android system | |
| 9.7″ pad digital camera | 9.7-inch lcd pad digital camera, android system | |
